Copper Sheet Strip Flat Bar 90 x 2 mm, 0.5 Meter Cut Length

Description

• Material: Copper with an electrically insulating enamel coating.
• Designation and standards: W200; EN 60317-13.
• Applications: Magnetic coils and magnetic technology; electric motors; transformer construction; wire insertion technology; ballasts; power tools; pump drives; generators.
• Properties: Density 8.92 g/cm; temperature index 210C; thermal pressure 350C; thermal shock 220C; electrical conductivity 5859 MS/m; elongation at break 2838%.
• Length tolerance: 2%.

Warning: sharp edges! The sheets are cut with a guillotine shear, and the edges are not deburred. Scratches on the surface cannot be ruled out. Product photos are for reference only; the supplied cut pieces may differ from them. The tolerance for the width and length of a cut sheet is 2 mm. Production time: none; already in stock. Shipping preparation: 23 business days. Delivery time depends on the parcel carrier. Flat copper wire is copper wire with an electrically insulating enamel coating. This wire has thermal class W200 and very high continuous temperature resistance. Flat enameled copper wire is highly resistant to thermal overload and chemicals, and has excellent mechanical strength and very good abrasion resistance. Flat copper wire has double enamel insulation. The insulation consists of modified polyesterimide with an additional polyamideimide coating. The wire cannot be tinned. Flat enameled copper wire is mainly used in magnetic coils and magnetic technology, electric motors, and transformer construction. Due to its good sliding properties, it is also suitable for wire insertion technology. Other application areas for flat copper wire include ballasts, power tools, pump drives, generators, and chemical plant construction. Flat copper wire is characterized by the following properties: very high continuous temperature resistance; high resistance to thermal overload; chemical resistance; excellent mechanical strength; very good abrasion resistance; double enamel insulation; cannot be tinned.
